COMPLIANCE & CERTIFICATIONS

Certifications
UL, CSA, CE, PSE and CCC

CONNECTIONS & COMMUNICATIONS

AC Operation
AC adapter, 90–260 VAC input, 5 VDC output to camera

Interface
USB Micro: Data transfer to and from PC and Mac device

WiFi
Standard: 802.11 b/g/n •Frequency range: •2400–2480 MHz •5150–5260 MHz •Max. output power: 15 dBm

ENVIRONMENTAL

EMC
WEEE 2012/19/EC •RoHs 2011/65/EC •C-Tick •EN 61000-6-3 •EN 61000-6-2 •FCC 47 CFR Part 15 Class B

Humidity (Operating and Storage)
IEC 60068-2-30/24 h 95% relative humidity

Operating Temperature Range
–15°C to 50°C (+5°F to 122°F)

Radio Spectrum
Standard: 802.11 b/g/n •Frequency range: •2400–2480 MHz •5150–5260 MHz •Max. output power: 15 dBm

Shock
25 g (IEC 60068-2-27)

Storage Temperature Range
–40°C to 70°C (–40°F to 158°F)

Vibration
2 g (IEC 60068-2-6)

Emissivity table/correction
Emissivity table of predefined materials/variable from 0.1 to 1.0

Encapsulation/Drop
IP 54 (IEC 60529)/2m (6.6 ft.)

IMAGING & OPTICAL

Camera weight incl battery
0.575 kg (1.27 lb.)

Color
Black and gray

Color palettes
Black & white, iron, and rainbow

f-number
1.5

Focus
Focus free

Image Adjustment
Automatic adjust/lock image

Image Frequency
9 Hz

Image Modes
Thermal MSX, Thermal, Picture-in-Picture, Thermal blending, Digital camera.

Minimum Focus Distance
0.5 m (1.6 ft.)

Picture-in-Picture
IR area on visual image

Spatial resolution (IFOV)
3.4 mrad

Spectral Range
7.5–13 µm

Digital Camera Resolution/FOV
640 × 480/55° × 43°

MEASUREMENT & ANALYSIS

Isotherm
Above alarm, below alarm

Reflected apparent temperature correction
Automatic, based on input of reflected temperature

Spot Meter
Center spot; box with min./max.

Spotmeter and Area
Center spot; box with min./max.

METER DATA

Display
3.0 in. 320 × 240 color LCD

PHYSICAL

Camera size (L x W x H)
244 × 95 × 140 mm (9.6 × 3.7 × 5.5 in)

Set-up Commands
Local adaptation of units, language, date and time formats
